Our Products
Silent Type Air Compresso
SP-S65V
SP-S65V
Power( HP )
1
Cylinder( Φmm x PCS / Stroke mm )
Φ65 x 2 / 44
Speed( rpm )
635
Displacement( l / min )
185
Pressure( Kg/cm2G )
7
Spec(LxWxH)( mm )
500 x 700 x 900
Weight( KG )
134
SP-S65T
SP-S65T
Power( HP )
2
Cylinder( Φmm x PCS / Stroke mm )
Φ65 x 3 / 48
Speed( rpm )
635
Displacement( l / min )
303
Pressure( Kg/cm2G )
7
Spec(LxWxH)( mm )
500 x 700 x 900
Weight( KG )
147
SP-S80V
SP-S80V
Power( HP )
3
Cylinder( Φmm x PCS / Stroke mm )
Φ80 x 2 / 60
Speed( rpm )
770
Displacement( l / min )
464
Pressure( Kg/cm2G )
7
Spec(LxWxH)( mm )
620 x 750 x 1030
Weight( KG )
204
SP-S80T
SP-S80T
Power( HP )
5
Cylinder( Φmm x PCS / Stroke mm )
Φ80 x 3 / 60
Speed( rpm )
850
Displacement( l / min )
769
Pressure( Kg/cm2G )
7
Spec(LxWxH)( mm )
620 x 750 x 1030
Weight( KG )
231
SP-S100V
SP-S100V
Power( HP )
7.5
Cylinder( Φmm x PCS / Stroke mm )
Φ100 x 2 / 70
Speed( rpm )
950
Displacement( l / min )
1045
Pressure( Kg/cm2G )
7
Spec(LxWxH)( mm )
750 x 900 x 1200
Weight( KG )
300
SP-S100T
SP-S100T
Power( HP )
10
Cylinder( Φmm x PCS / Stroke mm )
Φ100 x 3 / 70
Speed( rpm )
900
Displacement( l / min )
1484
Pressure( Kg/cm2G )
7
Spec(LxWxH)( mm )
750 x 900 x 1200
Weight( KG )
340
